Working Principle
Through the gearbox of the reducer to change the speed and direction, the milling knife and the pressing blade are rotated in opposite directions. When pressing the material, the material is pressed down by the inclined plane. Through the centrifugal force and the curve thrust, the grinding knife squeezes the material out of the screen cylinder mesh. Press to form the desired particles.
Main Features
- All sections contacting materials are made by stainless steel.
- This rotary granulator equipment is witnessed its high efficiency of granulation with fine particles.
- Its automatic material discharge is capable of avoiding particle damage caused by manual material discharge.
- For this reason, it is suitable for assembly line production.
Applications
ZL Rotary Granulator is mainly adopted in industries like pharmacy, food, instant granules, chemicals and solid beverage. The pre-mixed materials are produced into demanded particles and it is especially suitable for the materials having high viscosity.
Technical Parameters
Size of milling knife (mm) | 250 | 300B | 300D |
Particle Diameter (mm) | Φ2-2.2 be adjustable on request | Φ1.2-3 be adjustable on request | 0.5-6 be adjustable on request |
Motor Power (mm) | 700×540×1300 | 880×640×1300 | 1300×800×1200 |
Moter Power (can be adjustable on request) (kw) | 3 | 4 | 7.5-6 |
Weight (kg) | 350 | 400 | 780 |
Yield (kg/h) | 100-200 | 140-400 | 300-600 |
