Description
(Polyethylene Powder) Spray Dryer is the most widely used process in liquid shaping technology. It is suitable for producing powder and granules solid products from solution, emulsion, soliquoid, and pumpable paste materials. Therefore, when the particle size, final moisture, bulk density and granules shape meet the accurate standard, centrifugal spray drying is a ideal drying process.
Working Principle
The air passes through the filter and heater and enters the air distributor on the top of the centrifugal spray dryer. The hot air enters the dryer evenly in a spiral shape. The material liquid is pumped from the material liquid tank through the filter to the centrifugal atomizer on the top of the dryer, so that the material liquid is sprayed into very small mist droplets. The material liquid contacts the hot air in parallel, and the water evaporates quickly. It is dried into finished products within time, and the finished products are discharged from the bottom of the drying tower and the cyclone separator, and the exhaust gas is discharged by the fan.
Process characteristics of centrifugal spray dryer:
1. Feeding system: the liquid material is sucked by the pump to the granulation nozzle.
2. Spray system: the liquid material is atomized into micron-sized droplets by the granulating nozzle, and then enters the drying tower.
3. Heating system: It is composed of electric heater and hot air pipe to heat the atmospheric air to the high temperature air required by the process.
4. Drying tower system: It is composed of drying tower, hot air distributor, volute, lighting lamp, observation door, etc.
5. Product discharging and dust removal: cyclone separator, bottom collection bottle, tail bag dust collector, three points collection.
6. Electrical control system: Embedded touch control system.
Features:
1. High operational flexibility on non-adhesive or low-adhesive liquid materials.
2. Simple structure of the spray nozzle, easily used and maintained.
3. Less power consumption, low cost.
4. The hollow spherical product with big particles, good mobility and solubility.
5. Can be used to spray-cooling granulation process, such as paraffin, grease particles, special resins, etc.
Applicable Materials
Polyethylene Powder
Compound fertilizers, which contain N, P, and K, can often be produced by mixing straight fertilizers. In some cases, chemical reactions occur between the two or more components. For example, monoammonium and diammonium phosphates, which provide plants with both N and P, are produced by neutralizing phosphoric acid (from phosphate rock) and ammonia
Food: Amino acid, vitamin, egg powder, bone powder, protein, milk powder, blood powder, soy sauce powder, coffee, tea powder, glucose, pentadiene carboxylic acid, pectin, flavours, vegetable juice, yeast, starch, etc.
Ceramic: Alumina, zirconia, magnesium oxide, Titania, pottery clay, china clay, all kinds of magnetic porcelain and metal-oxides, etc.
Chemical: Aluminum polychloride, disperse dyes, reactive dyes, organic catalyzer, white carbon black, washing powder, zinc sulfate, silica, sodium metasilicate, potassium fluoride, calcium carbonate, potassium sulfate, inorganic catalyzer, wasted liquid, etc.
Specification
Type | Spray Dryer | |||||||
5 | 25 | 50 | 100 | 150 | 200-3000 | |||
Inlet Temperature | ≤ 350°C | |||||||
Outlet Temperature | 80-90°C | |||||||
Evaporate Capacity (kg/h) | 5 | 25 | 50 | 100 | 150 | 200-3000 | ||
Driving Force | compressed air drive | mechanical drive | ||||||
Rotate Speed | 25000 | 22000 | 21500 | 18000 | 18000 | 15000 | ||
Diameter of Atomizer (mm) | 50 | 120 | 120 | 120 | 150 | 180-340 | ||
Heating Source | Electricity | Electricity | electricity +steam+fuel oil+coal gas | electricity +steam | electricity +steam+fuel oil+coal gas | To be solved by users | ||
Electric-heating Power (kW) | 9 | 45 | 60 | 81 | 99 | |||
Recovery Rate (%) | ≥ 95 | ≥ 95 | ≥ 95 | ≥ 95 | ≥ 95 | ≥ 95 | ||
Installation Size | A(mm) | 1000 | 1290 | 1730 | 2500 | 2800 | ||
B(mm) | 2100 | 3410 | 4245 | 5300 | 6000 | |||
C(mm) | 2300 | 4260 | 4645 | 6000 | 6700 | |||
φ D(mm) | 1060 | 1800 | 2133 | 2560 | 2860 | |||
E1(mm) | 1050 | 1200 | 1640 | 2100 | 2180 | |||
E2(mm) | 1050 | 1200 | 1640 | 2100 | 2180 | |||
F(mm) | 750 | 1000 | 1250 | 1750 | 1970 | |||
G(mm) | 530 | 1700 | 1750 | 1930 | 2080 | |||
H(mm) | 530 | 1300 | 1800 | 2600 | 3050 | |||
I(mm) | 530 | 1550 | 1600 | 1780 | 1960 | |||
Packing & Delivery
The main equipment part will be wrapped in foam and then put into a carton; the main part will be packed in a wooden box. Both neutral and customized packaging are available.
We can deliver the equipment to you by international express such as DHL, UPS, TNT, EMS, etc., and we can also choose the appropriate transportation method according to your timeline and budget. In addition, you can choose to use your own shipping agent.
