Description
(White Carbon Black) Pneumatic Dryer is also called as Air Flow Dryer. From 1960s it is applied at pharmaceutical industry. At the beginning of 2000s, we began to choose the newest technology both at home and abroad and provide complete equipment with high quality and cheap price to pharmaceutical industry, chemical industry, foodstuff industry and so on. For many years, it has developed 4 series: Q series, QG series, FG series and JG series.
Working Principle:
In pneumatic dryer, the material to be dried is kept in a state of fine division, so that the surface per unit volume is high and high rates of heat transfer are obtained. Solids are introduced into the dryer by some form of mechanical feeder, such as a rotating star wheel, or by an extrusion machine arranged with a high-speed guillotine to give short lengths of material, such as 5–10 mm. Hot gases from a furnace, or more frequently from an oil burner, are passed into the bottom of the dryer, and these pick up the particles and carry them up the column. The stream of particles leaves the dryer through a cyclone separator and the hot gases pass out of the system. In some instances, final collection of the fine particles is by way of a series of bag filters. The time of contact of particles with the gases is small, typically 5 s, even with a lengthy duct — and the particle temperature does not approach the temperature of the hot gas stream. In some cases the material is recycled, especially where bound moisture is involved.
Applicable Materials
White Carbon Black Powder
Inorganic: borax, calcium carbonate, hydroxide, copper sulfate oxide, barium carbonate, antimony trioxide, all kinds of metallic hydroxide, all kinds of heavy metallic salt, synthetic cryolite and etc.
Organic: cadmium laurate, benzoic acid, germicide, sodium oxalate, cellulose acetate and etc.
Ceramics: silicone trioxide, clay and etc.
Dye: anthraquinone, black ferric oxide, indigo blue pigment, butyric acid, titanium hydroxide, zinc sulfide and etc.
Food: soya protein, agglomerative starch, wheat starch and etc.
Specification
Model | Water Evaporation (kg/h) | Total Power (kW) | Area (m2) | Height (m) |
Q50 | 50 | 6.25(8.25) | 20 | 8-10 |
QG50 | 50 | 6.25(8.25) | 20 | 8-10 |
JG50 | 50 | 9.25(11.25) | 20 | 8-10 |
Q100 | 100 | 8.6(11.6) | 32 | 10-12 |
QG100 | 100 | 8.6(11.6) | 32 | 10-12 |
JG100 | 100 | 16.1(19.1) | 32 | 10-12 |
Q250 | 250 | 20(27.5) | 64 | 14-16 |
QG250 | 250 | 20(27.5) | 64 | 14-16 |
JG250 | 250 | 31(38.5) | 64 | 14-16 |
Q500 | 500 | 33(48) | 96 | 14-16 |
QG500 | 500 | 33(48) | 96 | 14-16 |
JG500 | 500 | 48(58) | 96 | 14-16 |
Q1000 | 1000 | 63(78) | 120 | 14-16 |
QG1000 | 1000 | 63(78) | 120 | 14-16 |
JG1000 | 1000 | 78(98) | 120 | 14-16 |
